Bridge12 can design, model, fabricate and test custom vacuum devices for your microwave tube or accelerators. We have state-of-the-art design tools for performing a complete electrical and physics design followed by thermo-mechanical analysis.
Radio Frequency Quadrupole (RFQ) for a Proton Injector
This is part of a 600 MHz RFQ developed by Bridge12 for a 1.6 MeV Proton Injector. It is a fully brazed integrated vacuum assembly about 1 m long.
Boron Nitride Window for a Gyrotron
We can develop UHV assemblies that can handle high power. Shown to the left is part of a boron nitride window assembly for a 100 kW class W-band gyrotron. The completed assembly includes water cooling and custom weld flanges for integration with the gyrotron body.
Gyrotron Internal Mode Converter
A sub-assembly of an internal mode converter for a gyrotron is shown on the right.
